Hoshizaki 435490-01 Float Switch

Name: Hoshizaki 435490-01 Float Switch
Brand: Hoshizaki
SKU: HOS435490-01
Price: 92.95 USD
Availability: InStock

Hoshizaki
SKU: HOS435490-01

Condition: NEW

Quality: Highest (OEM — Original Equipment Manufacturer)

MPN: 435490-01 for exact fit and function.

The Hoshizaki 435490-01 is a float switch.

$92.95 ~~$97.20~~

Need Help?

Fit and Function

The switch mounts through a round flange and extends into a water reservoir or sump. As the water level rises and falls, the float body moves and actuates an internal electrical contact, opening or closing the circuit that signals the water level to the equipment's control system. A black and a red lead wire connect the switch into the control circuit.

Specifications

Housing: Black plastic mounting flange
Float Body: Light blue and white plastic
Leads: Black and red wire pairs

435490-01

Dimensions & Details:

Width: 4.15 in (10.54 cm)
Height: 3.85 in (9.78 cm)
Length: 5.2 in (13.21 cm)
Weight: 0.06 lbs (27.22 g)
Unit of Measure: Each (EA)
Manufacturer Code: HOS

Fits Models / Other Detail:

C-100BAF

C-100BAF-AD

C-100BAF-ADDS

C-100BAF-DS

C-101BAH

C-101BAH-AD

C-101BAH-ADDS

C-101BAH-DS

DCM-120FE

DCM-230FE-UK

DCM-240BAA

DCM-240BAB

DCM-240BAE

DCM-240BAF

DCM-270BAH

DCM-270BAH-OS

DCM-300BAH

DCM-300BAH-OS

DCM-450BAE

DCM-450BWE

DCM-500BAH

DCM-500BAH-OS

DCM-500BWH

DCM-500BWH-OS

DCM-700BAE

DCM-700BWE

DCM-750BAF

DCM-750BWF

DCM-751BAH

DCM-751BAH-OS

DCM-751BWH

DCM-751BWH-OS

DT-400BAH-OS

F-1000MAE

F-1000MAE-C

F-1000MAF

F-1000MAF-C

F-1000MLF

F-1000MLF-C

F-1000MRE

F-1000MRE-C

F-1000MRF

F-1000MRF-C

F-1000MWE

F-1000MWE-C

F-1000MWF

F-1000MWF-C

F-1001MAF

F-1001MAF-C

F-1001MAH

F-1001MAH-22C

F-1001MAH-C

F-1001MAJ

F-1001MAJ-C

F-1001MLF

F-1001MLF-C

F-1001MLH

F-1001MLH-C

F-1001MRF

F-1001MRF-C

F-1001MRH

F-1001MRH-C

F-1001MRJ

F-1001MRJ-C

F-1001MWF

F-1001MWF-C

F-1001MWH

F-1001MWH-C

F-1001MWJ

F-1001MWJ-C

F-1100MAA

F-1100MRA

F-1100MWA

F-1101ASU-1

F-1101AU

F-1101AWU

F-1500MAH

F-1500MAH-C

F-1500MRH

F-1500MRH-C

F-1500MWH

F-1500MWH-C

F-1501MAJ

F-1501MAJ-C

F-1501MRJ

F-1501MRJ-C

F-1501MRJ-SC

F-1501MWJ

F-1501MWJ-C

F-1501MWJ-SC

F-2000MLH

F-2000MRH-C

F-2000MRH3

F-2000MWH

F-2001MLH

F-2001MRH

F-2001MRH-C

F-2001MRH3

F-2001MRH3-C

F-2001MWH

F-250BAE

F-300BAF

F-330BAH

F-330BAH-C

F-450MAF

F-450MAF-C

F-450MAH

F-450MAH-C

F-500BAF

F-500BAF-C

F-800MAF

F-800MAF-C

F-800MAH

F-800MAH-C

F-800MWF

F-800MWF-C

F-800MWH

F-800MWH-C

F-801MAH

F-801MAH-C

F-801MWH

F-801MWH-C

FD-1001MAH

FD-1001MAH-C

FD-1001MRH-C

FD-650MAH-C

FD-650MRH-C

FD-650MWH-C

FS-1001MLH-C

FS-1022MLH-C

FS-1500MLH-C
